Managing APISIX Declaratively with APISIX Declarative CLI

APISIX users primarily use the Admin API to configure APISIX. But as your configurations increase in complexity, managing these only through the Admin API becomes more challenging.

To make things easier, we developed APISIX Declarative CLI, aka ADC, a tool that lets you define APISIX configurations declaratively.

In this article, we will look at how you can manage your APISIX configurations with ADC.

Deploying APISIX

Before we get started, we should first run an APISIX instance to interact with and configure. We can spin up APISIX in Docker by running:

curl -sL https://run.api7.ai/apisix/quickstart | sh

See the APISIX documentation to learn more about using APISIX.

Installing ADC

You can install ADC with the go install command:

go install github.com/api7/adc@latest

This will install the adc binary to your $GOPATH/bin directory.

export PATH=$PATH:$GOPATH/bin

If you don't have Go installed, you can also download the latest adc binary for your operating system and add it to your /bin folder as shown below:

wget https://github.com/api7/adc/releases/download/v0.2.0/adc_0.2.0_linux_amd64.tar.gz
tar -zxvf adc_0.2.0_linux_amd64.tar.gz
mv adc /usr/local/bin/adc

You can find binaries for other operating systems on the releases page. In the future, these binaries will be published on package managers like Homebrew.

To check if adc is installed, run:

adc --help

If everything is okay, you will see a list of available subcommands and how to use them.

Configuring ADC with Your APISIX Instance

To configure ADC to work with your deployed APISIX instance, you can run:

adc configure

This will prompt you to pass in the APISIX server address ('http://127.0.0.1:9180' if you followed along) and token.

If everything is correct, you should see a message as shown below:

ADC configured successfully!
Connected to APISIX successfully!

adc ping

Validating APISIX Configuration Files

Let's create a basic APISIX configuration with a route that forwards traffic to an upstream:

name: "Basic configuration"
version: "1.0.0"
services:
  - name: httpbin-service
    hosts:
      - api7.ai
    upstream:
      name: httpbin
      nodes:
        - host: httpbin.org
          port: 80
          weight: 1
routes:
  - name: httpbin-route
    service_id: httpbin-service
    uri: "/anything"
    methods:
      - GET

Once ADC is connected to the running APISIX instance, we can use it to validate this configuration before we apply it by running:

adc validate -f config.yaml

If the configuration is valid, you should receive a similar response:

Read configuration file successfully: config name: Basic configuration, version: 1.0.0, routes: 1, services: 1.
Successfully validated configuration file!

Syncing Configuration to APISIX Instance

You can now use ADC to sync your valid configuration with the connected APISIX instance. To do this, run:

adc sync -f config.yaml

This will create a route and a service as we declared in our configuration file:

creating service: "httpbin-service"
creating route: "httpbin-route"
Summary: created 2, updated 0, deleted 0

To verify if the routes were created properly, let's try sending a request:

curl localhost:9080/anything -H "host:api7.ai"

If everything is correct, you will receive a response back from httpbin.org.

Comparing Local and Running Configuration

Now let's update our local configuration in config.yaml file by adding another route:

name: "Basic configuration"
version: "1.0.0"
services:
  - name: httpbin-service
    hosts:
      - api7.ai
    upstream:
      name: httpbin
      nodes:
        - host: httpbin.org
          port: 80
          weight: 1
routes:
  - name: httpbin-route-anything
    service_id: httpbin-service
    uri: "/anything"
    methods:
      - GET
  - name: httpbin-route-ip
    service_id: httpbin-service
    uri: "/ip"
    methods:
      - GET

Before syncing this configuration with APISIX, ADC lets you check the differences between it and the existing APISIX configuration. You can do this by running:

adc diff -f config.yaml

You will be able to see the additions and deletions in the configuration and understand what changed before applying it.

Converting OpenAPI Definitions to APISIX Configuration

ADC also has basic support for working with OpenAPI definitions. ADC lets you convert definitions in OpenAPI format to APISIX configuration.

For example, if you have documented your API in OpenAPI format as shown below:

openapi: 3.0.0
info:
  title: httpbin API
  description: Routes for httpbin API
  version: 1.0.0
servers:
  - url: http://httpbin.org
paths:
  /anything:
    get:
      tags:
        - default
      summary: Returns anything that is passed in the request data
      operationId: getAnything
      parameters:
        - name: host
          in: header
          schema:
            type: string
          example: "{{host}}"
      responses:
        "200":
          description: Successfully return anything
          content:
            application/json: {}
  /ip:
    get:
      tags:
        - default
      summary: Returns the IP address of the requester
      operationId: getIP
      responses:
        "200":
          description: Successfully return IP
          content:
            application/json: {}

You can use the subcommand openapi2apisix to convert this to APISIX configuration as shown below:

adc openapi2apisix -o config.yaml -f openAPI.yaml

This will create a configuration file like this:

name: ""
routes:
- desc: Returns anything that is passed in the request data
  id: ""
  methods:
  - GET
  name: getAnything
  uris:
  - /anything
- desc: Returns the IP address of the requester
  id: ""
  methods:
  - GET
  name: getIP
  uris:
  - /ip
services:
- desc: Routes for httpbin API
  id: ""
  name: httpbin API
  upstream:
    id: ""
    name: ""
    nodes: null
version: ""

As you can see, the configuration is incomplete, and you would still need to add a lot of configurations manually. We are improving ADC to bridge this gap between OpenAPI definitions and what can be directly mapped to APISIX configuration.

Tip: Use Autocomplete

You can do a lot with ADC, and the list of features is bound to increase. To learn how to use any subcommand, you can use the --help or the -h flag, which will show the documentation for the subcommand.

To make things even easier, you can generate an autocompletion script for your shell environment using the completion subcommand. For example, if you are using a zsh shell, you can run:

adc completion zsh

You can then copy-paste the output to your .zshrc file, and it will start showing hints when you use adc.

ADC is still in its infancy and is being continuously improved. To learn more about the project, report bugs, or suggest features, visit github.com/api7/adc.
